Feelworld FW703

7" 3G-SDI 4K HDMI On-camera Monitor IPS Full HD 1920x1200

Viac informácií

380 € s DPH 316.67 € bez DPH
-+
Dostupnosť
7-14 dní
Výrobca
Doprava zdarma pri nákupe tohto produktu
Kód tovaru:
ART03799
Pridať do porovnania
Popis produktu

Popis produktu

7" 3G-SDI 4K HDMI On-camera Monitor IPS Full HD 1920x1200

Display Spec.

Model FW703
Screen Size 7" IPS
Resolution 1920x1200 pixels
Pixe Pitch 0.07875 (H) x 0.07875 (W) (mm)
Aspect Ratio 16:10
Brightness 450cd/m²
Contrast Ratio 1200:1
Backlight LED
Viewing Angle 80°/80°(L/R) 80°/80°(U/D)
Input
1 X BNC 3G-SDI
1 X HDMI HDMI
Output
1 X BNC 3G-SDI
1 X HDMI HDMI
Audio
Audio Stereo Headphone, Speaker
SDI Support Format
480i/576i
720p(60/59.94/50/30/29/25/24/23.98)
1080i(60/59.94/50)
1080p(60/59.94/50/30/29.97/25/24/24sF/23.98/23.98sF)
HDMI Input/ Output Support Format
480i/576i/480p/576p
1080i (60/59.94/50)
720p (60/59.94/50/30/29/25/24/23.98)
1080p (60/59.94/50/30/29.97/25/24/24sF/23.98/ 23.98sF)
4K UHD 3840×2160p (30/29.97/25/24/23.98Hz), 4096×2160p (24Hz)
General
Input Voltage DC6.5~24V
Power Consumption ≤9W
Working Temperature -20°C~55°C
Storage Temperature -30°C~65°C
Install Way 1/4"-20 Thread Socket (bottom)
Battery Plate F970 (Standard); D28S/D54, LP-E6, U60 (Optional)
Unit Size 180Lx120Hx22D (mm)
Unit Weight 320g/350g (With F970 Battery Plate)
Advanced Features

* Brightness Histogram

* Embedded Audio

* Peaking Focus Assist (Red, Green, Blue three colors optional highlight over parts of the image in focus)

* False Colors

* Zebra Exposure (1-100IRE adjustable)

* Check Field (Red, Green, Blue, Mono)

* Camera Mode

* Anamorphic Mode (1.3x, 2.0x, 2.0x mag)

* Image Flip (H, V, H/V)

* Image Freeze

* Center Marker

* Screen Marker (80%,85%,90%,93%,96%, 2.35:1)

* Ratio marker (4:3,13:9,14:9,15:9,16:9,1.85:1,2.35:1)

* Color Temperature Adjustment

* Nine Grid (Zoom one of the images to realize the full screen) (Nonsupport in 4K input)

* Zoom (4X, 9X, 16X) (Nonsupport in 4K input)

* Aspect Ratio (Nonsupport in 4K input)

* Pixel to Pixel (Nonsupport in 4K input)

* Zoom All (Nonsupport in 4K input)

* U/D Zoom (Nonsupport in 4K input)

* L/R Zoom (Nonsupport in 4K input)



Parametre

Parametre

Výrobca: Feelworld
Kategória: Monitory na kameru

Hlavné parametre

Napájení monitoruSony NP-F
Svítivost450cd/m2
Velikost7"
Vstupy monitora4K HDMI
Vstupy monitora3G-SDI
Rozlišení panelu1920x1200

Ostatné parametre

Dalšie funkcieLehký
