Yamaha AG08 biely

Yamaha AG08 WhiteAG08 je 8-kanálový live streaming mixážny pult s dvomi fantómovými vstupmi pre kondenzátorové mikrofóny, integrovaným USB audio rozhraním, meničom hlasu a samplerom.

Viac informácií

614 € s DPH 499.19 € bez DPH
-+
Dostupnosť
na otázku
Popis produktu ŠPECIFIKÁCIE OBSAH BALENIA

Popis produktu

Yamaha AG08 WhiteAG08 je 8-kanálový live streaming mixážny pult s dvomi fantómovými vstupmi pre kondenzátorové mikrofóny, integrovaným USB audio rozhraním, meničom hlasu a samplerom.

The AG08 is an 8-channel live streaming mixer featuring two phantom power inputs for condenser mics, an integrated USB audio interface, voice changer and sampler. By integrating more flexible I/O and USB routing options, expanded foot switch functionality, as well as additional DSP effects and improved internal circuitry for classleading sound, the AG08 is able to support an impressive depth of live streaming applications, as well as offline audio content creation. From single-user performances, to multiple personnel applications even on the scale of a full-blown variety show, the real-world, real-time functionality of the AG08 will leave your audience wanting more.

Features:

  • Two mic/line inputs and two headphone outputs can be used simultaneously
  • +48 V phantom power on CHI and two for condenser mics or DI boxes
  • Four FX preset buttons for CHI, Hi-Z input for guitars on CH2
  • Three stereo inputs with assignable faders, switchable input source for LINE/USB
  • 4-pole mini input/output (T RRS) on CH7/8
  • MONITOR outputs (XLR + TRS) and MIX outputs (TRS)
  • Six sound pads trigger audio samples in real time to add color to live streams
  • Internal circuitry delivers highest sound-quality in the AG series
  • 24-bit, 48 kHz Multi-channel audio recording and playback (Coexistence of ASIO and WDM)
  • Flexible inputs and outputs ideal for live streaming
  • DSP effects (Voice Changer, Amp Simulator, Comp, EQ, Reverb, Delay, Ducker, Maximizer)
  • AG08 Controller (Windows / Mac / iOS) for precise parameter control and detailed audio management
  • 60 mm faders and Mute buttons for each input
  • Footswitch functionality for more versatile system control
  • Windows / Mac support via USB-C connection
  • iOS connectivity via Apple Camera Adapter (requires external USB power supply)
  • Android supported by 4-pole mini input/output (T RRS)
  • Power input (AC/DC adopter 12 V, 1.5 A / USB-C 5 V, 1.5 A)
  • Cubase Al, WaveLab Cast, Cubasis LE are available



OBSAH BALENIA

  • AC adapter PA-150B
  • USB2.0 Cable (1.5 m)
  • Quick Guide
  • Safety Guide
  • Wavelab Cast Download Information
  • Cubase AI Download Information

ŠPECIFIKÁCIE

Input Channels Mono[MIC/LINE] 2 - CH1: Combo (Mic, +48 V phantom power / Line), 3.5 mm (1/8”) stereo mini (Headset mic, Plug-in power), CH2: Combo (Mic, +48 V phantom power / Guitar input / Line) *CH1 input and Headset mic cannot be used simultaneously
  Stereo[LINE] 3 - CH3/4: LR Stereo Phone, CH5/6: LR Stereo RCA/3.5 mm stereo mini (AUX), CH7/8: 4-pole mini in/out (TRRS)
  AUX 1 - Stereo mini
  Smartphone 1 - 4-pole mini input/output (TRRS)
  USB 1 - USB: 4 Stereo Audio Channels (Streaming, Voice, AUX, FROM DAW)
Output Channels PHONES 2 - CH1: 6.3 mm (1/4") Stereo / HEADSET mini PHONES *Cannot be used simultaneously, CH2: PHONES
  Smartphone 1 - 4-pole mini input/output (TRRS)
  MONITOR OUT 2 - LR Stereo: XLR, 1/4 TRS Phone
  STEREO OUT 1 - MIX: LR stereo TRS Phone
  USB 1 - USB: 4 Stereo Audio Channels (Streaming, Voice, AUX, TO DAW), 8 Channels Direct Out *In Windows environment, ASIO channel and USB 2.0 exist independently. Please check the block diagram for details.
Bus   4 Stereo
Functions   MUTE button x 5, CH1 FX preset button x 4, Sound pad x 6, +48 V phantom power x 2, GUITAR(HI-Z) x 1, PAD x 2, GAIN HIGH/LOW x 1, LINE/USB x 3, STREAMING ON/OFF x 3, CUE x 1, MIX MINUS (CH1, 2)
On-board processors DSP Voice Changer, Amp Simulator, COMP, EQ, REVERB (SPX Reverb), Delay, Ducker, Maximizer *Detail is operated on AG Controller
USB USB Audio 8 IN / 14 OUT, USB Audio Class 2.0 Compliant, Sampling Frequency: Max. 48 kHz, Bit Depth: 24-bit, Type-C
  USB DC Power input 1 - Type-C, 5 V DC, 1.5 A
General specifications
Power requirements   DC 12 V, 1.5 A / USB-C 5 V, 1.5 A
Power consumption   Max. 7.5 W
Dimensions W 290 mm (11.5")
  H 88 mm (3.5")
  D 222 mm (8.8")
Net weight   2.2 kg (4.9 lbs)
Included Accessories   AC adapter PA-150B, USB2.0 Cable (1.5 m), Quick Guide, Safety Guide, Wavelab Cast Download Information, Cubase AI Download Information
Others   Operating Temperature: 0 to + 40 ℃
